Featuring an interesting new take on the usual three-knob EQ section, the Bass and Treble controls use traditional “tone stack” technology, yielding a familiar bright chime based on 50 years of tradition, while the active Mid control provides a more strongly voiced cut/boost function for increased versatility. Increasing the Mid control boosts the frequencies that give an aggressive “D-Style” bite to the sound, while decreasing Mid brings out that familiar clean-60’s Blackface tone.
Weighing the same 2 pounds as its little brother, the 101 Reverb is so light you’ll think we forgot to put the guts in! Even with the same compact footprint, it has more than enough power to bring any cabinet to life!
Power Output: 0 to 50 watts maximum, 4-8 ohms
AC Power Req.: 100–240Vac, 50–60 Hz, 100 W maximum
Input Connections: ¼” mono, 2M input impedance, 2V peak
Effects Send: ¼” mono, 1V full scale, 600 ohms
Effects Return: ¼” mono, 1V full scale, 47K
Headphone Output: 1/4″ jack, 4V peak
Speaker 1 Output: 8 ohms, 60-100 W recommended rating
Speaker 2 Output: 4 ohms, 60-100 W recommended rating
Dual Speakers 1+2 8 ohms each, 30-50W recommended rating.
H x W x D 8.5”(218mm) x 7.5” (190mm) x 3” (76mm)
Weight 2 lbs (0.9kg)
